The Right Board for Underfloor Heating
In an underfloor heating system, the insulation board is the bottom layer. It is the most important layer. Without it, heat goes down into the floor below. Your room does not get warm. Our thermal boards for underfloor heating are made specifically for this job. They lock the heat inside your room. We are an old factory with 23 years of XPS experience. We were the first XPS company in southern Zhejiang. We have ISO 9001 and ISO 14001. We are a green building material company. Our thermal boards for underfloor heating are eco-friendly and effective.
High Strength and Low Heat Transfer Parameters
This board must handle the weight of heating pipes and concrete screed. It has high compressive strength. See the details:
|
Parameter |
Value |
|
Board Size |
1800×600 mm |
|
Thickness |
20 mm (standard) |
|
Compressive Strength |
250 kPa |
|
Thermal Conductivity |
≤0.034 W/(m·k) |
|
Water Absorption |
≤1.5% |
|
Dimensional Stability |
≤1.5% |
Many underfloor heating projects in Wenzhou have used our thermal boards for underfloor heating. So have heating upgrades in northern Chinese cities. Customers come back for repeat orders. That is the best proof of quality.
Easy to Lay and Export-Ready
You lay the board on the leveled floor slab. Butt the joints tightly. Tape the seams with aluminum foil tape. Then lay the reflective film. Then lay the heating pipes. Then pour the screed. No special tools needed. Workers already know these steps. For export orders, we use stretch film, edge protectors, and pallets. Sea shipping is safe. We have done export for many years. One-year warranty. Choose our thermal boards for underfloor heating for a warm home and lower heating bills.
Furthermore, we offer boards with pre-grooved surfaces. The grooves are exactly spaced for standard pipe diameters (16 mm or 20 mm). This makes pipe installation much faster. You just snap the pipes into the grooves. No need for plastic clips or ties. We can also customize the groove pattern based on your drawings. This service is very popular among underfloor heating contractors. Minimum order for pre-grooved boards is 100 square meters. Choose our thermal boards for underfloor heating for faster installation and lower labor costs.
