Block Heat Transfer Between Different Zones
Sometimes you do not need to insulate an entire room. You just need to stop heat from moving from one area to another. For example, between a boiler room and an office, or between a hot pipe and a wall. Our heat barrier insulation board is made for these situations. It acts as a thermal break. You place it between the heat source and the area you want to keep cool. The board's low thermal conductivity stops heat from crossing over. This is different from standard insulation, which covers large surfaces. A heat barrier is targeted and efficient. We have 23 years of experience making XPS boards. We have supplied products to Samsung Xi'an, SK Hynix Wuxi, and Sanmen Nuclear Power Plant. Those projects required precise heat control. Our heat barrier insulation board helped them achieve that.
Technical Specifications for Industrial Use
This board is available in various thicknesses and compressive strengths. It also comes with optional flame retardant grades. See the key parameters:
|
Parameter |
Value |
|
Board Size |
1800×600 mm (custom widths up to 1200 mm) |
|
Thickness |
10 mm to 100 mm (custom up to 200 mm) |
|
Compressive Strength |
200 kPa to 1000 kPa (select based on load) |
|
Thermal Conductivity |
≤0.034 W/(m·k) |
|
Water Absorption |
≤1.5% |
|
Flame Retardant Grade |
B1 or B2 (optional, must be specified) |
|
Density |
25–32 kg/m³ (higher density available) |
Our heat barrier insulation board is often used in industrial settings: between steam pipes and control panels, behind ovens, around furnace walls, and in HVAC separator walls. It is also used in commercial kitchens to isolate heat from cooking equipment.
Custom Cutting and Fast Delivery
Because heat barriers often need to fit into tight or irregular spaces, we offer custom cutting services. Tell us the exact dimensions you need. We will cut the boards before shipping so you do not have to cut them on site. This saves time and reduces waste. For standard thicknesses, we keep stock and can ship within 7–10 days after deposit. Custom orders take 15–20 days. We support EXW, FOB, and DDP terms. Payment is 30% deposit, 70% balance. We also provide a one-year warranty. If the board cracks or shrinks under normal use, we replace it. Choose our heat barrier insulation board for precise, reliable heat separation in demanding environments.
